The MediCap USB 300 HD is a portable video-capture system designed to record clinical displays and procedural video to USB storage media. It accepts video input via HDMI, DVI, or HD-SDI (depending on configuration), encodes the signal to MPEG-4 H.264 format at 1920 × 1080p resolution, and writes the stream to USB flash drives or external hard drives. Audio is captured via RCA input. A front-panel button set (Record, Stop, Play) with LED status indicators controls operation; HDMI pass-through allows simultaneous live display on an external monitor during recording. The unit runs on standard AC power (100–240V) via an included medical-grade adapter. - HDMI, DVI, or HD-SDI video input (model-dependent) - MPEG-4 H.264 encoding at full HD resolution - USB storage (flash drive or external hard drive) - RCA audio input - HDMI pass-through for live monitoring
Service manuals, configuration guides, and spec sheets — captured from OEM and vendor sites, plus documents contributed by approved vendors.
Compare by price, lead time, and warranty in the quote response.
Request quote
