Mindray AG Module
Model Number: 6800-30-50411, 6800-30-50502
Device✓ 1 in stock
The Mindray AG Module is a sidestream anesthetic-gas monitor that integrates with Mindray BeneView and compatible Mindray patient monitors. It measures inspired and expired concentrations of CO2, O2, N2O, and five anesthetic agents (Halothane, Isoflurane, Enflurane, Sevoflurane, …
Overview
The Mindray AG Module is a sidestream anesthetic-gas monitor that integrates with Mindray BeneView and compatible Mindray patient monitors. It measures inspired and expired concentrations of CO2, O2, N2O, and five anesthetic agents (Halothane, Isoflurane, Enflurane, Sevoflurane, Desflurane), with automatic agent identification and real-time Minimum Alveolar Concentration (MAC) calculation. The module connects to the monitor via its modular interface and displays all measured parameters on the shared screen. Configurable sampling rates and alarm thresholds accommodate different clinical workflows. Two model variations are available: - 6800-30-50411: Standard 5-agent monitoring - 6800-30-50502: Enhanced configuration support
Tech Info
- Measured Parameters: EtCO2, FiCO2, EtO2, FiO2, EtN2O, FiN2O, agent concentrations (Halothane, Isoflurane, Enflurane, Sevoflurane, Desflurane)
- Sampling Method: High-precision sidestream
- Sampling Rate: Configurable
- MAC Display: Real-time calculation
- Agent Identification: Automatic
- Alarms: Adjustable high/low limits for all measured gases and MAC
- Compatibility: Mindray BeneView and compatible Mindray patient monitors
- Models: 6800-30-50411 (standard), 6800-30-50502 (enhanced)
Common Problems
- Gas module failure without display of parameters.
- Power or communication loss between module and monitor.
Specifications
- Model 1
- 6800-30-50411
- Model 2
- 6800-30-50502
- MAC Display
- Real-time
- Sampling Method
- Sidestream
- Compatible Monitors
- Mindray BeneView and compatible Mindray monitors
- Measured Parameters
- EtCO2, FiCO2, EtO2, FiO2, EtN2O, FiN2O, anesthetic agent concentrations
- Agent Identification
- Automatic
- Anesthetic Agents Supported
- Halothane, Isoflurane, Enflurane, Sevoflurane, Desflurane
Vendor offers (1)
Compare by price, lead time, and warranty in the quote response.
- PurchaseIn stockPrice
Request quote
